Type / Brand - Pneucon Automation
Type / Brand - Pneucon Automation
Description of globe 2 way valve (piston operated valve)
Body Designed and Manufactured as per ASME B 16.34.
SEAT LEAKAGE : As per FCI-70-2 Class IV, V and VI.
Metal to Soft Seating Bubble tight (Zero Leakage).
FEATURES
• Simple construction provides ease in maintenance without disturbing insulations and piping connections.
• Y seal used in cylinder provides good pressure seals with minimum friction.
• Diaphragms used are made of special Nitrile to sustain Air pressure upto 6 kg/cm2.
• Compact design hence reduced weight and low cost.
• Long life over 100 thousand cycles.
• Spring loaded construction allows to move the plug to either top or bottom of it's stroke, if supply pressure failure occurs.
Body MOC - Cast Iron, Carbon Steel, Stainless Steel (Special on request).
|
Characteristics |
: |
On / Off |
|---|
|
Actuator Type |
: |
Piston (Yoke / Yokeless), Diaphragm |
|---|
|
Actuator Action |
: |
Direct / Reverse / Double Acting |
|---|
|
|
|
Direct acting air failure "Closes" |
|---|
|
|
|
Direct acting air failure "Opens" |
|---|
|
|
|
Double Acting air failure "stayput" |
|---|
|
Spring Ranges |
: |
1-2kg / cm2, 2-4 kg / cm2, 3-5 kg / cm2 |
|---|
|
Air Connection |
: |
1/4" NPT |
|---|
|
Size |
: |
1/2" (15 mm) to 4" (100mm) |
|---|
